Product Description
EndGlow® is ideal for use with architectural lighting fixtures, landscape fixtures, water-tight lenses, feature lights, and adaptable for EndGlow® signage.
*Note: When ordering cable, specify length by quantity in terms of feet. Spools are established lengths and will not be cut shorter; if specific lengths are required, order each individual cable cut to length. SV150EG, SV225EG, SV300EG, SV150EGW, SV225EGW, and SV300EGW are not available in 1000’ spool lengths.
Product Support
EndGlow Cable Specification Sheet



Product Specifications
Construction EndGlow® cable is multi-strand fibers protected in a flexible PVC jacket for ease of handling and fiber protection.
Warranty 2 years
Cabling Diameters are based on fiber quantity
4 fibers .125" (3.2mm)
12 fibers .219" (5.5mm)
25 fibers .25" (6.35mm)
50 fibers .312" (7.9mm)
75 fibers .375" (9.5mm)
150 fibers .59" (15.1mm)
225 fibers .625" (15.9mm)
300 fibers .687" (17.5mm)
